HIKVISION 16 Port PoE Switch (DS-3E0318P-E/M)

16 Port Fast Ethernet Unmanaged POE Switch

Intelligent PoE Management. When the power supply exceeds the limit, PoE ports intelligently manage the power supply, which extends the switch lifetime.
Up to 300 m Long Range PoE Transmission. The distance between IPCs and switch can reach maximum 300 meters.
4/8-Core Adaptive Power Supply with Less Power Loss. 8-core power supply reduces the power loss on cables.
6KV Surge Protection to Improve Reliability in Harsh Environment. The built-in surge protection device protects the switch from the sudden lightning surge in harsh environment.
Design for Video Transmission. VIP port ensures important data transmission when network congestion occurs.
Specification:
PoE Power SupplyPoE StandardIEEE 802.3af, IEEE 802.3atPoE Power PinPorts for long-distance transmission (9-16) support 8-core power supply, Ethernet cable 1/2/3/6 and 4/5/7/8 provide simultaneous power supply.Ports for close-range transmission (1-8) support 4-core power supply, Ethernet cable 1/2/3/6 provide power supply.PoE PortPorts 1 to 16Max. Port Power30 WPoE Power Pudget130 WMax. Power Consumption150 WNetwork ParametersPort Number16 × 100 Mbps PoE ports, 1 × 1000 Mbps RJ45 port, and 1 × 1000 Mbps SFP fiber optical portPort TypeRJ45 port, full duplex, MDI/MDI-X adaptiveStandardIEEE 802.3, IEEE 802.3u, IEEE 802.3xForwarding ModeStore-and-forward switchingWorking ModeStandard mode (default); Extend modeHigh Priority PortsPorts 1 to 8Ports For Long-Distance TransmissionPorts 9 to 16MAC Address Table4 KSwitching Capacity7.2 GbpsPacket Forwarding Rate5.356 MppsInternal Cache2.75 MbitsGeneralShellMetal materialGross Weight2.58 kg (5.69 lb)Net Weight1.8 kg (4.0 lb)Dimension (L × H × D)266 mm × 44.5 mm × 220.8 mm (10.5” × 1.8” × 8.7”)Operating Temperature-10 °C to 55 °C (14 °F to 131 °F)Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)Operating Humidity5% to 95% (no condensation)Storage Humidity5% to 95% (no condensation)Power Supply100 to 240 VAC, 50/60 Hz, Max. 2.5 APower Consumption In Idle20 WApprovalEMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
