CP Plus 20amp 12V 16x CCTV Power Supply (CP-DPS-PD16V2-12D)

P-DPS-PD16V2-12D (16 Channel Power Supply)

16 Channel Output
With Cable Compensation Switch
LED Indicator for Each Channel
Built-in EMI Filter to Nullify Interference
Cooling by Free Air Convection
Built-in Constant Current Limiting Circuit
100% Full Load Built-in test
Plastic Housing
Input voltage 180~264V AC
Output voltage 12V DC
Current Range 0~8A
Rated Power 96W
Ripple & Noise (max.) 120mVp-p
Voltage Adj. Range 11.4~12.6V
Line Regulation ±1.0%
Voltage Tolerance n/a
Setup Rise time 2500ms, 15ms at full load
Hold Up Time (Typ.) 35ms at full load
Load Regulation ±5.0%
Temperature coefficient ±0.03%/°C (0~50°C)
Frequency Range 47~63HZ
Efficiency (Typ.) 86%
AC Current (Typ.) 2A/220VAC
Inrush Current (Typ.) Cold Start: 50A/220V AC
Leakage Current <2mA / 240VAC
Over Load 110~200% rated output power, Protection type: Shut down O/P, recovers automatically
Isolation Resistance I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500V DC / 25°C/ 70% RH
Working Humidity 20 ~ 90% RH Non-condensing
Vibration 10 ~ 500Hz, 3G 10min./1 cycle, 60min. each along X, Y, Z
Dimension 186(L) x 130.5(W) x 39mm(H)
Store temperature -20 ~ +85°C
Working temperature -20 ~ +45°C
Withstand Voltage I/P-O/P: 1.5KVAC I/ P-FG: 1.5KVAC O/ P-FG: 0.5KVAC
